MegEye-W4K-E82 (Readable HID iClass card)

ShenXing 8" MEGPass Face Recognition Access Control Terminal

Available Now

MegEye-W4K-E82 is a facial recognition terminal of the MEGVII hardware product family. This device provides safe,fast, and smooth passing experience for customers by its cutting-edge algorithm based on deep learning, and the infra +RGBcameras. It is mainly applied in the security access control scenarios of mansion lobby, school, airport and logistic center, etc. This device is waterproof and dustproof.

Recognition

100,000 face capacity, accuracy > 99.8%, speed≤200 ms.

Light Adaptability

Working in different light environment, even in 0 lux dark scene.

Multi-Card support Support M1.HID ICLASS Card

Anti-Spoofing

RGB+IR liveness detection, effectively defending against various forms of attacks such as photos, 3D paper models.

Multifunction

Supporting multiple authentication such as card and QR codes. Capable of connecting with various peripheral modules such as POE power supply, temperature screening module, etc.

Integration

Rich REST API and SDK make integration very easy and friendly.



Specification

Model: MegEye-W4K-E82-N0

System

Face Capacity

100,000

Operation System

Linux

Main Processor

DV300

RAM

1G

ROM

8G

Screen Size

8-inch

Camera resolution

2MP RGB + 2MP IR

Fill Light

IR

Internet

Network Interface

1*100M Ethernet Port

Wi-Fi

Support 2.4G Frequency Wi-Fi IEEE802.11 b/n/g

Bluetooth

Bluetooth4.0 +LE

Interface

Lock output

1

Door contact output

1

Exit button input

1

Alarm input

2

Alarm output

1

Wiegand

wiegand 34/26, 1 in /1 out

RS485

1

USB

USB2.0 *1; USB TypeC*1

Reset Button

1

Tamper Button

1

Card

M1 type

Support

HID iClass

Support

HID Seos

Support

Power

Adapter

12V,2A, not included

PoE

not support defaultly support PoE expander

Audio

Mic Reserved

Speaker Support (less than 90dB)

General

Language

English, Thai, Japanese

Housing Materials

PC+ABS; Aluminum alloy frame

Working Temperature

-30°C~65°C

Mask Recognition

Support

Working environment

Indoor and Outdoor

Dimensions

230mm x127.6mm x17.6mm

Protective Level

IP66/IK05

Installation

Wall mount/ Pole mount/ Turnstile

Certification

CE

Optional Model

MegEye-W4K-E82-N0

Standard Model

MegEye-W4K-E82-HID-N0

Optional model, support HID card

Power adapter for Japan

Power Head: KPL-040F-VI Power line:CH-1123+CH-1112

Power adapter for Europe

Power Head: G99-ACB024F-N022 Power line:45H7515EU-001
